This appears to be a specification string or part description for an industrial ventilation fan system. It describes a specific application, material compatibility, and performance requirements.
Breaking down the keywords:
- Gas Delivery: The fan is used in a system that delivers gas (likely a combustible or industrial process gas, or possibly exhaust).
- Nickel Iron Kiln: This is the application environment. A Nickel Iron Kiln is a high-temperature furnace (pyrometallurgical) used to process nickel and iron ores (e.g., in the RKEF process for ferronickel). The atmosphere is extremely hot, dusty, and corrosive.
- Silencer: A sound attenuation device (muffler) is required, indicating the fan generates significant noise (high pressure/flow).
- 14122 Pa: This is the static pressure requirement: 14,122 Pascals.
- Conversion: ~2.05 PSI or ~56.6 inches of water gauge (in. w.g.).
- Implication: This is a high-pressure fan (likely a centrifugal blower, not a standard axial fan). It needs to overcome significant resistance from the kiln, ducts, and the silencer.
- Ventilation Blower Fan: The device type. For this pressure, it will be a radial/centrifugal blower.
What is needed for this application?
Given the context (Nickel Iron Kiln + 14kPa pressure), you are likely looking for a heavy-duty industrial centrifugal fan with specific features:
- Type: Most likely a "Paddle Wheel" or "Radial Blade" fan, or a robust Airfoil/Backward Inclined fan designed for high pressure and particulate-laden gas.
- Construction Materials:
- Impeller: High-temperature alloy (e.g., 310S Stainless Steel or Inconel) to handle kiln gas heat and the nickel-rich dust.
- Housing: Carbon steel with high-temperature lining or heavy-duty stainless steel to resist corrosion from process gases (often containing sulfur or chlorine).
- Motor: High-power motor (likely 75 kW to 200+ kW range) with a Variable Frequency Drive (VFD) for controlled gas delivery.
- Sealing: Shaft seals capable of handling hot, potentially toxic gas to prevent leakage into the environment.
- Silencer: Inline, rectangular, or cylindrical silencer designed for low-frequency noise attenuation (high-pressure fans produce dominant low-frequency noise).
How to Source or Specify This Fan
If you are trying to purchase this, the string is a shorthand query. A professional sales engineer would need the following clarifications:
- Gas Temperature: (e.g., 150°C ambient? 400°C process gas? Up to 800°C?)
- Flow Rate (Volume): (e.g., 10,000 m³/h? 50,000 CFM?) Pressure alone is not enough; you need CFM/m³/hr.
- Gas Composition: Is this air? Off-gas? Combustible gas? (Determines ATEX/hazardous area rating).
- Dust Load: Is the gas dirty? (Determines impeller design and wear protection).
- Location: Indoor/outdoor? Ambient conditions?
Recommendation: You should contact a supplier specializing in Pyrometallurgical Ventilation or High-Temperature Process Fans (e.g., companies like New York Blower, Robinson Fans, Howden, or TLT-Turbo). Provide them with the exact parameters (Temperature, Volume Flow, Pressure, Gas Type) rather than just the description string.
