This appears to be a highly specific, industrial-grade product description, likely for a piece of heavy machinery used in power generation or chemical processing. Let's break down what each part of that name means to define the product accurately.
Here is the breakdown of "Aluminium Alloyed Antiwear CFB Boiler Explosion Proof Blower Centrifugal Fan" :
Core Function: Centrifugal Fan / Blower
- What it is: A fan that moves air or gas by drawing it into the center of a rotating impeller and flinging it outward at high speed using centrifugal force.
- Purpose: It is designed to force large volumes of air into a boiler system to facilitate combustion (burning fuel).
Application: CFB Boiler
- CFB (Circulating Fluidized Bed) Boiler: This is the specific boiler type.
- Operating Conditions: CFB boilers operate with high-pressure air, extreme temperatures, and a highly abrasive environment. The air is used to "fluidize" a bed of fuel (like coal, biomass, or waste) and sand/limestone.
Safety Feature: Explosion Proof
- Why it's needed: In a CFB boiler, the air/gas mixture can contain combustible dust (coal dust, biomass dust) or flammable gases. A spark or high heat from a standard electric motor could trigger an explosion.
- What it means:
- The motor is enclosed in a flame-proof housing that can contain an internal explosion and prevent it from igniting the external atmosphere.
- The impeller and housing are designed with smooth shapes and non-sparking materials.
- The electrical connections are sealed.
Durability Feature: Antiwear (Abrasion Resistance)
- The Problem: CFB boilers use "fluidized bed material" (sand, ash, limestone). This material is extremely abrasive. Standard fans would be destroyed quickly by the dust particles hitting the impeller blades at high speed.
- The Solution: The fan is constructed with antiwear properties. This usually involves:
- Hard-faced impeller blades: A layer of very hard alloy (like stellite or chrome carbide) welded onto the leading edges.
- Wear liners: Thick, replaceable plates on the fan housing and volute.
- Thicker material: Using a heavier gauge of steel (e.g., 10mm or 12mm plate instead of 6mm).
Material: Aluminium Alloyed (Likely a Mistranslation or Specific Constraint)
- The Conflict: This is the most unusual and potentially problematic (or highly specific) part.
- Typical Antiwear Fans: Are made from High Tensile Steel (like Q345R or Corten) or Hardox because steel is tough and can be hard-faced.
- Aluminum Alloy is typically not used for antiwear fans because it is soft and has low abrasion resistance.
- The Likely Explanation (Why "Aluminium Alloyed" is mentioned):
- Sparks Prevention: Since the fan is Explosion Proof, the manufacturer might require a non-sparking material for the impeller. Aluminum alloys are naturally non-sparking (unlike steel, which can spark when it hits rust or metal debris).
- "Aluminum Alloyed" as a Term: It might be a mistranslation of "Aluminized" (steel coated with aluminum for corrosion/heat resistance) or a specific Marine-Grade Aluminum (like 5083) used for the housing to save weight, while the impeller is still steel.
- Specific Design: If the fan is handling corrosive flue gas (common in waste-to-energy or high-sulfur coal), the housing might be aluminum (corrosion-resistant) while the impeller is steel (wear-resistant). This is rare but possible.
Summary of the Product
What is it? A heavy-duty, high-pressure industrial blower specifically designed to supply combustion air to a Circulating Fluidized Bed Boiler. It is built to survive the extreme heat, pressure, and abrasion of the coal/biomass dust inside the boiler system without causing an explosion.
Key Specifications:
- Type: Centrifugal Fan
- Application: Primary Air (PA) or Secondary Air (SA) fan for a CFB boiler.
- Safety Rating: Explosion Proof (likely Ex-d or Ex-nA standard).
- Durability: Heavy-duty antiwear construction (thick steel with hard-facing).
- Material (Conflicting): Likely a Hybrid Design (Steel impeller with Aluminum housing) OR a mistranslation for an Aluminum-alloyed coating/casing for spark resistance. Pure aluminum would not survive the wear.
If you are sourcing this part, beware of the "Aluminium Alloyed" term. Clarify with the supplier:
- Is the impeller made of steel or aluminum?
- If aluminum, how do they achieve abrasion resistance?
- If steel, is the housing aluminum to prevent sparks?
A more accurate product name would be: "Explosion-Proof CFB Boiler Forced Draft Fan with Abrasion-Resistant Steel Impeller" . The aluminum term is likely a specific alloy requirement for the housing to prevent sparking in a Zone 1 or Zone 2 hazardous area.
