Based on your query for a 15kW Dust removal centrifugal induced draft fan, this is a specific industrial equipment specification. Here is the breakdown of what this usually means, its typical specifications, and key uses.
What It Is
- 15kW (Kilowatts): The motor power is 15 kW. This is roughly equivalent to 20 horsepower. This power level is suitable for medium to large industrial dust collection systems.
- Centrifugal: The fan moves air by centrifugal force. Air is drawn into the center of a rotating impeller and thrown outward to the discharge. This design generates high static pressure, which is essential for moving dusty air through long ducts and filter systems.
- Induced Draft: The fan is placed after the dust collection filters (e.g., baghouse or cartridge filters). It pulls (induces) air through the system, creating negative pressure. This prevents dust from leaking out of ducts and enclosures.
Typical Specifications for a 15kW Induced Draft Fan
| Parameter | Typical Value | Notes |
|---|---|---|
| Motor Power | 15 kW (20 HP) | Usually a TEFC (Totally Enclosed Fan Cooled) induction motor, 3-phase. |
| Voltage | 380V / 415V (3-Phase) | Common industrial voltage. Check local standards (e.g., 460V in some North American plants). |
| Airflow (CFM / m³/h) | 15,000 – 25,000 m³/h (8,800 – 14,700 CFM) | This is a rough estimate. Actual airflow depends heavily on the system's static pressure (duct length, filter type). |
| Static Pressure (mmH₂O / Pa) | 1500 – 2500 Pa (150 – 250 mmH₂O) | High pressure is typical for induced draft applications to overcome filter resistance. |
| Impeller Type | Backward Curved or Radial Blades | Backward curved are more efficient. Radial blades are better for heavy, sticky dust. |
| Construction | Heavy-duty steel, often with wear-resistant coating or stainless steel lining for abrasive dust. |
Key Applications (Uses)
- Baghouse or Cartridge Dust Collectors: The most common application. The fan pulls air through filter bags or cartridges.
- Woodworking:
- Shops with central chip collection systems.
- MDF sanding and cutting (fine, explosive dust).
- Metalworking & Welding:
- Plasma cutting tables (removing smoke and fumes).
- Grinding and polishing booths.
- Chemical & Pharmaceutical:
- Conveying powders.
- Ventilation for reactors or mixing vessels.
- Cement & Mining:
Conveying dry, abrasive dust from crushers and screens.
Important Considerations & Accessories
- Filter Type: Ensure the fan's pressure rating matches your filter's pressure drop (clean + dirty).
- Spark Resistance: For combustible dust (wood, metal, grain), the fan must be spark-resistant (e.g., aluminum impeller or non-ferrous tip).
- Inlet Box: Often needed to connect to filter outlets smoothly.
- Variable Frequency Drive (VFD): Highly recommended for a 15kW fan to:
- Adjust airflow (dampers waste energy).
- Soft-start the motor.
- Balance the system.
- Safety: Induced draft fans handle already-filtered air (mostly clean), reducing wear on the impeller compared to a "forced draft" fan that handles raw dust.
Comparison: Induced Draft vs. Forced Draft
| Feature | Induced Draft (ID) | Forced Draft (FD) |
|---|---|---|
| Position | After filters (on clean air side) | Before filters (on dirty air side) |
| Pressure | Negative (suction) | Positive (blowing) |
| Dust load | Very low (clean air) | High (raw dust) |
| Wear | Low | High |
| Danger | Low (clean air) | Risk of dust explosion if fan is not spark-proof |
Pricing Note (Rough Estimate 2024)
A complete 15kW centrifugal induced draft fan (fan + motor + base) typically costs between $3,000 USD and $8,000 USD, depending on:
- Material of construction (carbon steel vs. stainless steel).
- Brand (e.g., New York Blower, Chicago Blower, Loren Cook, or Chinese/Indian manufacturers).
- Accessories (VFD, inlet box, silencer, etc.).
Bottom Line
A 15kW dust removal centrifugal induced draft fan is a powerful, specialized unit for industrial dust collectors. It is designed to pull air through filter systems, not to blow raw dust into ducts. For proper selection, you must know your system's required airflow (m³/h) and resistance (static pressure) .
