It sounds like you are looking for a 45kW centrifugal fan designed for material conveying, which requires large air volume and low pressure. This is a very specific industrial application, typically used in pneumatic conveying systems for moving materials like wood chips, grains, pellets, dust, or light scrap.
Here is a detailed breakdown of what this specification means, typical applications, and key design features you should look for.
Core Understanding: "Large Air Volume, Low Pressure"
- Low Pressure: In the context of a 45kW fan, "low pressure" usually means Static Pressure in the range of 200 to 1,000 Pa (approx. 0.8 to 4 inches of water gauge). It is not a high-pressure blower (like a Roots blower), but it must overcome friction loss in ducts and the weight of the material.
- Large Air Volume (Flow Rate): A 45kW fan at low pressure moves an enormous amount of air.
- Estimate: A well-designed 45kW low-pressure fan can move 90,000 to 150,000 m³/h (approx. 53,000 to 88,000 CFM). The exact flow depends on the specific pressure and impeller design.
Key Applications (Material Conveying)
- Woodworking & Biomass: Conveying wood chips, sawdust, shavings, and bark.
- Agriculture: Moving grains (corn, wheat), soybeans, pellets, and animal feed.
- Waste Management: Conveying light municipal solid waste, paper, and plastics.
- Food Processing: Moving seeds, nuts, coffee beans, or powdered ingredients.
- Power Plants / Cement: Moving pulverized fuel or light fly ash (low-pressure side).
Critical Design Features for a Material Conveying Fan
A standard ventilation fan will fail quickly under erosive material loads. You need a heavy-duty, abrasion-resistant design.
| Feature | Why it's Critical for Material Conveying |
|---|---|
| Impeller Type | Paddle blade (radial) or flat-blade (not airfoil). These are stronger and less likely to clog. They create a "flinging" action for material. |
| Rotor Construction | Heavy-gauge steel plate, fully welded. Backplate should be thick (e.g., 10-12mm for 45kW). Use a shrouded or open/plate design depending on material stickiness. |
| Housing (Casing) | Scroll type, heavy-gauge steel (e.g., 6-8mm). Must have removable wear liners (AR steel, rubber, or ceramic tiles) on the scroll and side plates where material impacts. |
| Shaft & Bearings | Oversized shaft. Use split pillow block bearings with cooling fins. Locate bearings outside the housing to keep dust and material out. |
| Drive System | Belt drive is preferred. It allows you to adjust fan speed (and thus flow/pressure) by changing sheaves. A motor sheave should be sized correctly. Direct drive is possible but less flexible. |
| Motor | 45kW (typically 60 HP), 4-pole (1500/1800 RPM), TEFC (Totally Enclosed Fan Cooled), IE3 efficiency. Fit a VFD (Variable Frequency Drive) for speed control and soft start. |
| Evase / Discharge | Use an evase (a gradual expanding duct at the outlet) to recover static pressure and reduce velocity, saving energy. |
| Abrasives Handling | For conveying sand, glass, or heavy dust, the fan MUST have hard-faced (Stellite) or replaceable wear plates. Standard mild steel will wear holes in weeks. |
Example Selection / Sizing (Approximate)
- Motor Power: 45 kW (60 HP)
- Flow Rate: ~100,000 m³/h (59,000 CFM)
- Static Pressure: ~800 Pa (3.2 in. w.g.)
- Fan Speed: ~750 - 1000 RPM (belt driven)
- Impeller Diameter: ~1,400 mm (55 inches)
- Inlet/Outlet: Typically 800mm x 800mm or larger.
Important: This is a guide. The exact fan curve must be matched to your system's resistance (duct length, elbows, material load). Material load (concentration) is measured in "kg of material per kg of air". For low pressure, a typical ratio is 0.5 to 1.5 kg/kg.
How to Buy / Search
When contacting suppliers, use these exact phrases:
- "45kW heavy-duty centrifugal fan for pneumatic conveying"
- "Low pressure, high volume material handling fan"
- "45kW paddle blade fan with wear liners"
- "Industrial fan for wood chip / grain conveying"
Sellers (Global Examples):
- Greenheck (BH or BHS series - BSH is heavy duty)
- New York Blower (General Industrial Fans - GI series)
- Howden / Clarage (Custom heavy-duty fans)
- Arranging / Aerowood (Specialized in woodworking fans)
- Fischbach / Pollrich (European heavy-duty)
- Local Chinese OEMs (e.g., YIFAN, CT Fan) – often most cost-effective if you specify correct materials.
A Critical Warning: Static vs. Dynamic Pressure
In material conveying, the fan generates Static Pressure (SP) to overcome friction. However, Velocity Pressure (VP) is crucial to keep material suspended.
- Low Pressure design (under 1,000 Pa SP) means the air velocity must still be high enough (e.g., 20-30 m/s in ducts) to pick up and carry the material.
- If you need to convey heavier materials (large wood chips, dense grains) at high rates, you actually need a medium pressure fan (1,000 to 3,000 Pa) at 45kW. In that case, your air volume will be lower (e.g., 40,000 m³/h).
Conclusion: A 45kW low-pressure centrifugal fan is a powerful yet gentle mover of light, bulky materials. It is an excellent choice for systems with long runs and many pick-up points (e.g., central vacuum systems or plant-wide trim removal). Ensure the fan is built with abrasion-resistant internals and a belt drive for flexibility.
